型号Model

DN

PN

LW

d1

i

L

L1

B

H

h1

h2

h3

SW1

S

KHB3K-SAE4

6

315

6

SAE4

12

69

37

28

44.5

13

34

8

9

35

KHB3K-SAE6

10

315

10

SAE6

13

72

42

32

52.5

17

40

8

9

36

KHB3K-SAE8

13

315

13

SAE8

15

83

48

37

52.5

17

40

8

9

40

KHB3K-SAE12

20

315

20

SAE12

20

95

60

48

75

24

54

12

12

49

KHB3K-SAE16

25

315

25

SAE16

20

113

65

55

82

28.5

61

12

12

56.5

KHB3K-SAE20

25/32

315

25

SAE20

20

120

65

60

82

28.5

61

12

12

60

KHB3K-SAE20

32

315

30

SAE20

20

120

84

75

104.5

37.5

84

14

14

60

KHB3K-SAE24

40

315

38

SAE24

20

130

91

85

115.5

42.5

95

14

17

70

KHB3K-SAE32

50

315

48

SAE32

20

140

100

105

133

52.5

112.5

14

17

75
