型号Model

DN

PN

LW

RA

d1

i

L

L1

B

H

h1

h2

h3

SW1

SW2

KHB-M12x1.25

4

500

4

8

M12x1.25

9

61

37

28

44.5

13

34

8

9

 24

KHB-M16x1.5

6

500

6

11

M16x1.5

11

69

37

28

44.5

13

34

8

9

24

KHB-M22x1.5

8

500

8

16

M22x1.5

12

76

42

32

52.5

17

40

8

9

27

KHB-M27x1.5

10

500

10

20

M27x1.5

12

76

42

32

52.5

17

40

8

9

32

KHB-M30x1.5

16

400

15

24

M30x1.5

13

84

47

38

63.5

19

46

11

9

32

KHB-M36x2

20

315

20

30

M36x2

15

103

60

48

75

24

57

12

12

41

KHB-M42x2

25

315

25

35

M42x2

18

116

65

57

82

28.5

64

12

12

46

KHM-M52x2

32

315

30

40

M52x2

20

149

84

82

108

41

87.5

14

14

55

KHM-M60x2

40

315

38

50

M60x2

22

174

91

93

119.5

46.5

99

14

17

70

KHM-M72x2

50

315

48

60

M72x2

24

178

100

110

135.5

55

115

14

17

80
